Robustel's R5020 Lite offers next-generation cellular connectivity at a highly competitive price. Offering 3G, 4G/LTE, and 5G global band coverage in a small footprint, the R5020 Lite enables rapid deployment of high-speed IoT applications across verticals as diverse as transportation, enterprise connectivity, and digital signage.
The R5020 Lite is Robustel's new 5G-compatible router that supports global 5G, 4G, and 3G bands. The R5020 Lite leverages our proven high-performance CPU platform and RobustOS 5, an operating system developed in-house by Robustel that has passed extensive third-party penetration testing.
R5020 Lite is compatible with 3GPP version 16 and is aimed at the following applications:
Failover : R5020 Lite can be configured to use Ethernet or Wi-Fi as the primary internet and switching to 5G/4G in the event of an outage. This can help bring resiliency to small stores and offices at a reasonable cost and provide enough bandwidth for many users. IPsec, DMVPN, GRE+ many more protocols can be used for connections to core networks.
Cellular router - Cellular network operators can now offer unlimited 5G tariffs at very reasonable prices. For many, the opportunity to cut cords and use a wireless internet connection can be technically or commercially advantageous.
SD-WAN : While many devices have built-in cellular options, the R5020 Lite can offer a very inexpensive way to add a 5G backup path, and by virtue of being able to locate outside of the device, you're more likely to get a good 5G signal!
RCMS is Robustel's free router monitoring service that is fully compatible with the R5020 Lite. It is an extremely polished piece of software hosted on MS Azure and available as a privately hosted instance. You can try out Robustel's free router management platform by signing up here: https://rcms-cloud.robustel.net
Key features
- Low-cost 5G industrial router
- 5G/4G/3G Global Cellular Connections
- Next-generation 3GPP version 16 5G cellular interface
- Supports Ethernet, Wi-Fi, and 5G/4G Internet with automatic failover
- 1 RS232/RS485 port (software configurable) for connection to industrial/legacy devices
- Fully programmable operating system with well-documented SDK
- There are several VPN options available, including DMVPN, IPsec, L2TP, and more...
- Free Cloud Management Platform – RCMS
- Robust metal enclosure with a small footprint – options for wall or DIN rail mounting
| Cellular Interface | |
| Number of antennas | 4 (ANT0 + ANT1 + ANT2 + ANT3) |
| Connector | SMA-K |
| SIM | 2 x Mini SIM (2FF) |
| Ethernet Interface | |
| Number of ports | 2 x 10/100/1000 Mbps, |
| 2 LAN by default, can be configured as | |
| 1 WAN + 1 LAN | |
| Isolation protection | 1 KV |
| WiFi Interface | |
| Number of antennas | 2 (WiFi1 + WiFi2) |
| Connector | RP-SMA-K |
| Standards | 802.11b/g/n/ac 2*2 MIMO, supports AP and Client modes |
| Frequency bands | 2.412 – 2.472 GHz (2.4 GHz ISM band)5.15 – 5.825 GHz (5 GHz ISM band) |
| Security | WPA, WPA2, WEP, WPA3* |
| Encryption | AES, TKIP, WEP64 |
| Data speed | 5G: Up to 867Mbps2.4G: Up to 300Mbps |
| Serial Interface | |
| Number of ports | 1 x RS232 or 1 x RS485 (Configurable Software) |
| Connector | 1 x 3-pin 3.5 mm female socket |
| ESD protection | ±8 KV air discharge, ±6 KV contact discharge |
| Baud rate | 300 bps ~ 115200 bps |
| Signal definition | RS232: TXD, RXD, GNDRS485: Data+ (A), Data- (B), Ground (GND) |
| Others | |
| Reset button | 1 x RST |
| LED indicators | 1 x RUN, 1 x Modem, 1 x USR, 1 x RSSI, 1 x Wi-Fi 2.4G, 1 x Wi-Fi 5G |
| Built-in | Watchdog |
| Software (Basic features of RobustOS) | |
| Network protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, VLAN, SSH2, DDNS, etc. |
| VPN tunnel | IPsec, OpenVPN, GRE |
| Firewall | DMZ, anti-DoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
| Management | Web, CLI, SMS |
| Serial port | Transparent, TCP Client/Server, UDP, Modbus RTU to TCP |
| Others | Data Guard, etc. |
| SDK | |
| Supported programming languages | C, C++ |
| Flash available for SDK | 5MB |
| RAM available for SDK | 128MB |
| App Center (Available Apps for RobustOS) | |
| Apps* | L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Language, RCMS, Dynamic Route,Data Guard, Captive Portal, WLAN Multi AP |
| *Upon request .For more Apps please visit www.robustel.com. | |
| Power Supply and Consumption | |
| Connector | 2-pin 3.5 mm female socket with lock |
| Input voltage | 12~36 VDC |
| Power consumption | Idle: 370 mA@12 VData link: 1.7 A (peak) @12 V |
| Physical Characteristics | |
| Ingress protection | IP30 |
| Housing & Weight | Aluminum, 475 g |
| Dimension | 136 x 115 x 32 mm |
| Installations | DIN rail mounting, desktop or wall mounting |
| Operating Temperature | -20 ~ +55°C (Normal temperature)-25 ~ +70°C (Extended temperature) |
| Storage Temperature | -40 to +85 °C |
| Relative Humidity | 5 to 95% RH |
| Regulatory and Type Approvals | |
| Environmental | RoHS2.0 |
| Physical Features | IEC 60068-2-6 (Sinusoidal Vibration)IEC 60068-2-64 (Random Vibration)IEC 60068-2-27 (Mechanical Shock) |
| EMI | EN 55032 Conducted Emission Class BEN 55032 Radiated Emission Class B |
| EMC | EN 61000-3-2 (Harmonic Current) |
| EN 61000-3-3 (Voltage Flicker)EN 61000-4-2 (ESD) Contact Level 3, Air Level 3EN 61000-4-3 (RS) Level 3EN 61000-4-4 (EFT) Power Ports Level 2Signal Ports Level 3EN 61000-4-5 (Surge)Line to line Level 2, Line to ground Level 3EN 61000-4-6 (CS) Level 3EN 61000-4-11 (Dips) Class 2 | |
| Model | PN | Frequency Bands* | Country/Region | Certification (* Planned ) |
| R5020L-A-5G-A25GL | B098004 | 5G : NR SA/NSA: n1/n2/n3/n5/n7/n8/n12/n13/n14/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n71/n75/n76/n77/n78/n79 4G : LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71LTE TDD: B34/B38/B39/B40/B41/B42/B43/B48LAA: B46 (only supports 2 x 2 MIMO) 3G : WCDMA: B1/B2/B4/B5/B8/B19 | Global | CB, CE, UKCA, RCM, TELEC, JATE |
*For more information about frequency bands in different countries, please contact your Robustel sales representative.
